MikroTik
hEX
hEX with Dual Core 880MHz MHz CPU, 256MB RAM, 5 Gigabit LAN ports, USB, RouterOS L4, plastic case, PSU
hEX is a five port gigabit ethernet router for locations where wireless connectivity is not required. The device has a USB 2.0 port. This new updated revision of the hEX brings several improvements in performance.
It is affordable, small and easy to use, but at the same time comes with a very powerful dual core 880MHz CPU and 256MB RAM, capable of all the advanced configurations that RouterOS supports. IPsec Hardware encryption and dude server package is supported, microSD slot on it also provides improved r/w speed for database storage on microSD card.
Performance comparison
| Previous r2 | 64 byte | 1518 byte | 1400 byte |
|---|---|---|---|
| Bridging | 396 Mbps | 986 Mbps | 986 Mbps |
| Routing | 373 Mbps | 986 Mbps | 986 Mbps |
| AES-128 | 9 Mbps | 52 Mbps | 50 Mbps |
| New r3 | 64 byte | 1518 byte | 1400 byte |
|---|---|---|---|
| Bridging | 523 Mbps | 1972 Mbps | 1972 Mbps |
| Routing | 530 Mbps | 1972 Mbps | 1972 Mbps |
FEATURES
hEX (revision 3)
880 MHz CPU, 2 cores and 4 threads
256 MB RAM
microSD slot for “Dude Server” support
Full size USB
IPsec hardware acceleration
Same form factor
Same price
Specifications
| Product code | RB750Gr3 |
|---|---|
| CPU nominal frequency | 880 MHz |
| CPU core count | 2 |
| Size of RAM | 256 MB |
| 10/100/1000 Ethernet ports | 5 |
| PoE in | Yes |
| Supported input voltage | 8 - 30 V |
| PCB temperature monitor | Yes |
| Voltage Monitor | Yes |
| USB | Yes, type A 2.0 |
| Hardware encryption | Yes |
| Dude server package support | Yes |
| Dimensions | 113x89x28mm |
| License level | 4 |
| Operating System | RouterOS |
| CPU | MT7621A |
| Max Power consumption | 5 W |
Included parts
Power adapter
Salvador G.
June 2, 2023
WAN Mode: Single-WAN
Functionality:quite extended
Quality:high
Material:pretty decent Secured with a non standard default password. Excellent after sales service !!
G***.
May 9, 2023
WAN Mode: Dual-WAN LoadBalance
Fast and good quality. Small and compact. Will install once my fiber is here.
Vincent
April 30, 2023
WAN Mode: Single-WAN
Functionality:working well
Quality:good
Material:good way better than most of the router in the market. value for money
D***.
March 23, 2023
WAN Mode: Dual-WAN LoadBalance
Excellent product and excellent support
D***.
March 14, 2023
WAN Mode: Single-WAN
Thanks for the fast (2 day) delivery. Single WAN configuration worked out of the box (password is the serial number, not blank as instructed in the manual.) Built-in ATik firewall rules seem good. Successfully set up IPv6 by following online guides. You may want to increase default DHCP lease time from 00:10:00 to 1d 00:00:00
Vic
March 4, 2023
WAN Mode: Single-WAN
Not plug and play for me (SingTel ISP) but managed to get help from seller to change some settings through downloaded Winbox app on PC. Works well now.
Nicholas T.
Feb. 6, 2023
WAN Mode: Dual-WAN LoadBalance
works well right out of the box. plugged in and able to connect, no need to configure on my part.
Tio S.
Jan. 17, 2023
WAN Mode: Dual-WAN LoadBalance
Excellent support staff to deal with router issue.
9***3
June 14, 2022
WAN Mode: Dua-WAN LoadBalance
Excellent product. Preconfigured and works out of the box.
James L.
April 24, 2022
WAN Mode: Single-WAN
fast delivery and feature packed router for those seeking a simple dual wan solution with LACP
M***.
April 23, 2022
WAN Mode: Single-WAN
Amazing out of the box configuration that works with no hassle. After service has been stellar so far with knowledge rep. Helped me understand my complicated network requirements and guided me to products and solutions to make it work.
N***.
April 3, 2022
WAN Mode: Single-WAN
Very affordable router with very good protection. Just plug and play without the need to configure anything. Speedtest shows 940+ Mbps which is considered good as it is near my 1 Gbps fibre plan.
Rye
March 20, 2022
WAN Mode: Dua-WAN LoadBalance
Supports are professionals and knowledgeable, helpful and prompt. Product works as expected. Configurations that came with the device is suffice for most of its usage.
9***6
Nov. 30, 2021
WAN Mode: Single-WAN
Packing was good. Delivery was fast. User friendly, plug and play. Very good build quality.
Victor L.
Oct. 30, 2021
WAN Mode: Single-WAN
MikroTik lives up to its fame. Powerful features packed into a tiny but capable box for less than $100. Customisation and support is enterprise-level by a certified network / security engineer with deep knowledge, service is prompt and effective. Apprehension allayed, VPN gateway up and routing load alleviated from wireless. Cheers !!!
